Name: GLOWING STICKMAN SET = 7.5 metres EL Wire + Driver
SKU: STIKMAN_
Price: 29.99 GBP
Availability: InStock

GLOWING STICKMAN SET = 7.5 metres EL Wire + Driver

£29.99 – £54.99

This glowing stickman set is plug and play and made up of the following:

6 x 1 metre lengths of 3.2mm EL Wire.
3 x 50cm lengths of 3.2mm EL Wire.
Choice of EL wire colours.
A powerful portable driver with an 8 x AA battery pack (batteries not supplied) or a rechargeable Li-ion battery.
The driver will have spare capacity as it is rated to make 15m of EL wire glow.
1 x long 3-way splitter, 2 x standard 3-way splitters, 1 x mini 5-way splitter, 1 x mini 3-way splitter plus a 50cm extender.
50 Clear Hoops for ease of attachment of EL Wire to the costume and removal for washing.

Show less

Description

1) 6 pieces of 1 metre 3.2mm EL Wire

2) 3 pieces of 50cm 3.2mm EL Wire

3) An EL Driver with either an 8 x AA Power Pack (batteries not supplied) or a rechargeable 3000mAh Li-ion battery (only available in the UK due to airmail postal restrictions)

This driver is powerful enough to glow up to 15 metres of EL Wire

4) 1 x Long 3 Way Splitter, 2 x 3 Way Splitter, 1 x Mini 5 Way Splitter and for the head, a Mini 3 Way Splitter and a 50cm Extender

By ‘daisy chaining’ the Splitters you can have all 9 metres of EL Wire attached to this one driver/inverter

5) 50 x Clear Hoops to make it easy to attach the EL Wire to the costume and also make it removable so you can put it through the washing machine

hoops for attaching el wire to clothing

The EL Wire can be any combination of these colours:

Light Blue, Lime Green, Pink, Red, Orange, Purple, Yellow, Deep Blue, Turquoise-Green and White

The whole kit is ready to use – just plug and play!

stickman layout guide

Here is the suggested layout

Dimensions of the products:

If you are making a costume it is important to plan it out properly.

For this glowing man set, the driver/inverter is very powerful and so it comes with a choice of separate power packs.

So here are the dimensions of all the parts plus lengths of wire between them.

THE POWER PACK

Takes 8 x AA batteries (not supplied) and is 12.7cm x 7.02cm x 1.9cm and has a 19cm thin power wire coming out of it that leads to the driver

A 3000mAh rechargeable Li-ion battery which weighs 172g and is 7.3cm x 5.6cm x 2.2cm. This option comes with a 1A intelligent charger. Due to airmail restrictions this is option is only available for UK delivery.

THE DRIVER

The driver is 5.4cm x 3.4cm x 2.9cm and has controls on it – Off, Flashing or On. It has a 55cm wire coming out of it that leads to the…

SPLITTER

The Splitter is 40cm long in total,

it is 20cm of wire which then splits into 3 separate strands which are all 20cm long and lead to the…

EL WIRE

There is then another 20-25cm from the connector until the actual glowing start of EL Wire – then there is 2 X 3metres of gorgeous glowing wire!

1 x 3 metre is for the body

1 x 3 metre is for the legs

ANOTHER SPLITTER!

leads to more…

EL WIRE

20-25cm from the connector until the glowing start of 3 x 50cm EL Wire

These are for the really fun part of designing the expression on the face of your stickman/girl

Its not complicated or fiddly – I’ve just given all those details if you want to plan your costume before you buy the set

stickman layout guide

The stickguys and stickgals in these pictures were designed by international party animal Jak Hammer and his amigos!
We have some crazy glowing masks & glasses that go well with this kit – take a look!
